Saw blade Thickness 8mm
Tooth pitch 7-100mm
Circular saw outside diameter 80-815mm
Bore hole diameter 10-220mm
Hook angle of grinding -20 degree-40degree
Tooth face angle of grinding -15degree+15degree
The rear angle of grinding 6-45 degree
Left-right pitch of tooth Tooth tip :45degree Tooth face:45degree
Range of Grinding Cycle 0-30mm
Wheel speed 6000 r/min
The Speed of Work 24 teeth/min
Total Power 1.69kw
Cooling Device 25L/min
Grinding wheel outside dia. 32mm-125mm
Net weight 960kg
Gorss weight 1100kg
Overall size 1650*1350*1830mm
